Запчасти Komatsu PC45R-8 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

20T-60-82121

TRAVEL MOTOR ASS'Y

|$3

20T-60-82120

TRAVEL MOTOR ASS'Y

|$5

TZ573B200001EA

HYDRAULIC MOTOR A.

1

TZ573B2002-00

SHAFT

2

TZ573B200300-E

PLATE,SWASH

3

TZ510B2004-01

BLOCK,CYLINDER

4

TZ510B2105-00

PISTON KIT (9 PIECES)

5

TZ310B2007-01

PLATE,RETAINER

6

TZ310B2008-00

BOWL,THRUST

7

TZ550A2009-00

PLATE,TIMING

8

TZ310B2010-00

WASHER

9

TZ571B2012-02

PISTON

10

TZ550A2013-00

SPRING

11

TZ510B2014-00

SPRING

12

TZ571B2015-00

PLATE

13

TZ550A2016-00

PLATE

14

TZ15Z-17-35-8

SEAL,OIL (K1)

15

TZ571B2035-01

O-RING (K1)

16

TZ571B2039-01

O-RING (K1)

17

TZJB1354-4-10

PIN

18

01252-30820

BOLT

19

TZ310B2032-01

PLATE,THRUST

20

TZIRTW-32

RING

21

TZ510B2029-00

BEARING

22

06000-06201

BEARING

23

TZJB15062-208F

PIN

23

TZJB1506-2-208

PIN

24

TZ573B2070-00

PISTON ASS'Y

25

TZ534B2076-01

PIVOT

26

TZ310B2074-00

PLATE

27

TZ534B2077-00

PIN

28

TZ571B2078-01

O-RING (K1)

29

TZ573B2085-00

SPRING
