Запчасти Komatsu PC45R-8 РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$3

20T-70-01120

ARM ASS'Y

|$4

20T-970-0120

ARM ASS'Y,(FOR ATTACHMENT)

|$5

20T-70-01310

ARM ASS'Y,(FOR MULTI)

1

ARM

1

ARM

1

ARM,(FOR ATTACHMENT)

1

ARM,(FOR ATTACHMENT)

1

ARM,(FOR MULTI)

2

20T-70-81250

BUSHING

3

20T-70-25740

BUSHING

4

20T-70-71880

BUSHING

5

07145-00050

SEAL,DUST

6

07145-00045

SEAL,DUST

7

07020-00675

FITTING,GREASE

8

07020-00000

FITTING,GREASE

9

20T-62-82271

HOSE, 1100MM

9

20T-62-82270

HOSE

9

20T-62-82170

HOSE

10

08037-05022

GROMMET

11

203-62-58650

COVER

12

08034-00519

BAND

13

20S-70-71571

PIN

13

20T-70-71230

PIN

14

07020-00000

FITTING,GREASE

15

04082-00212

LOCK

16

01010-81230

BOLT

17

01643-31232

WASHER

18

20T-70-81780

SPACER, 1.0MM

18

20T-70-19130

SPACER, 1.0MM

19

20S-70-71571

PIN

20

04082-00212

LOCK

21

01010-81230

BOLT

22

01643-31232

WASHER

23

20T-70-81710

SPACER, 1.0MM

23

20T-70-19130

SPACER, 1.0MM

24

20T-63-X2524

CYLINDER GROUP,BUCKET

24

20T-63-X2580

CYLINDER GROUP,BUCKET (FOR MULTI)
