Запчасти Komatsu PC45MRX-1 МОТОР ХОДА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

20U-60-42111

MOTOR ASS'Y

|$3

TZ411D1000-02

FINAL DRIVE ASS'Y

|$4

SPINDLE KIT

|$5

SPINDLE ASS'Y

1

SPINDLE

2

FRANGE,HOLD

3

TZ550A1019-00

BOLT,REAMER

4

TZ410D1035-00

BOLT

|$10

RV GEAR ASS'Y

5

RV GEAR

6

SHAFT,CRANK

7

SPACER

8

BEARING

9

BEARING

|$16

TZ410D1107-00

SPUR GEAR KIT

10

SPUR GEAR

|$18

TZ18820528A627

SEAL KIT,FLOATING

11

SEAL,FLOATING (K1)

12

TZ411D1001-01

HUB

13

TZ410D1006-01

GEAR,INPUT

14

TZ410D1008-01

COVER

15

TZ410D1017-01

PIN

16

TZ550A1018-00

RING

17

TZ860A1013-00

SNAP RING SET

18

TZ410D1021-00

BEARING

19

04064-01510

RING,SNAP

20

04064-02512

RING,SNAP

21

07000-11008

O-RING (K1)

22

07000-05200

O-RING (K1)

23

TZARP568-249-7

O-RING (K1)

24

TZ410D1033-00

PLUG

25

TZ810B2021-00

PLUG

26

07000-12014

O-RING (K1)

27

TZ534B2077-00

PIN

K-1

TZ419D9000-00

SERVICE KIT

|$38

07000-11008

O-RING

|$39

07000-05200

O-RING

|$40

TZARP568-249-7

O-RING

|$41

TZ100188BA627

SEAL,FLOATING

|$42

07000-12014

O-RING

|$43

TZ15Z-17-35-8

SEAL,OIL

|$44

TZ571B2035-01

O-RING

|$45

TZ410D2039-00

O-RING

|$46

07000-11007

O-RING

|$47

TZJB2401-P22-9

O-RING

|$48

07000-12012

O-RING
