Запчасти Komatsu PC45MRX-1 ЭЛЕКТРОПРОВОДКА (Э/ПРОВОДКА) (ЕС ARRANGEMENT)(№89-) ЭЛЕКТРИКА

1

22M-06-12213

WIRING HARNESS

1

22M-06-12212

WIRING HARNESS

1

22M-06-12211

WIRING HARNESS

1

20T-06-81230

FUSIBLE LINK

1

21X-06-31530

DIODE

1

08020-00000

DIODE

1A

22L-06-18930

SOCKET

2

08038-10525

CAP

3

08038-12027

CAP

4

08038-10519

CAP

5

22M-06-11152

BRACKET

5

22M-06-11151

BRACKET

6

01010-81225

BOLT

7

01643-31232

WASHER

8

04434-51712

CLIP

9

04434-51412

CLIP

10

01010-81025

BOLT

11

01643-31032

WASHER

12

01010-81020

BOLT

13

01643-31032

WASHER

14

22M-06-11432

CABLE

14

22M-06-11431

CABLE

15

01010-81030

BOLT

16

01643-31032

WASHER

17

362-60-12210

SPACER

18

22M-06-11261

BRACKET

19

08160-71200

HORN

19

08160-61200

HORN

20

01010-80816

BOLT

21

01643-30823

WASHER

22

08036-00814

CLIP

23

01010-81020

BOLT

24

01643-31032

WASHER

25

22M-06-11170

WIRING HARNESS

26

20T-06-71560

FUSE BOX

27

22M-06-11340

PLATE, FUSE

28

201-06-61240

FUSE, 30A

29

283-06-16190

FUSE, 10A

30

22W-06-13160

FUSE, 20A

31

20T-54-71550

BOLT

32

22M-06-11360

COVER

33

01010-D0816

BOLT

33A

01643-70823

WASHER

34

01010-D0870

BOLT

35

01643-70823

WASHER

36

22M-06-11410

GROMMET

37

08053-01510

CLIP

38

01010-81016

BOLT

39

01643-31032

WASHER

40

04434-52112

CLIP

41

07095-20314

CUSHION

42

01010-81020

BOLT

43

01643-31032

WASHER
