Запчасти Komatsu PC45MRX-1 ATTCHMENT ЛИНИЯ ГИДРАВЛИКА

1

20T-62-71150

UNION

2

07002-11823

O-RING

2A

02896-11012

O-RING

3

22N-973-1340

TUBE

3

22M-973-1440

TUBE

4

22M-973-1433

BRACKET

4

22M-973-1432

BRACKET

5

01010-80825

BOLT

5

01010-80825

BOLT

6

01643-30823

WASHER

6

01643-30823

WASHER

7

07283-32236

CLIP

8

01597-01009

NUT

9

01643-31032

WASHER

10

02766-00403

HOSE

10

22M-973-1350

HOSE, 280MM

11

02762-005A6

HOSE

11

02765-005A4

HOSE

11

22M-973-1120

HOSE, 420MM

12

22N-973-1870

HOSE

12

22N-973-1750

HOSE, 890MM

12

22M-973-1130

HOSE, 600MM

13

22N-973-1350

TUBE

13

22M-973-1451

TUBE

13A

02896-11015

O-RING

14

01010-81030

BOLT

15

01643-31032

WASHER

16

22M-973-1460

BRACKET

17

01010-81225

BOLT

18

01643-31232

WASHER

19

22N-973-1730

HOSE, 2050MM

19

22M-973-1334

HOSE

19

22M-973-1333

HOSE

19

22M-973-1332

HOSE

20

22N-973-1720

HOSE, 1780MM

20

22M-973-1344

HOSE

20

22M-973-1343

HOSE

20

22M-973-1342

HOSE

21

22M-973-1410

CUSHION

21

22M-973-1410

CUSHION

22

22M-973-1421

PLATE

22

22M-973-1420

PLATE

23

01010-81025

BOLT

23

01010-81025

BOLT

24

01643-31032

WASHER

24

01643-31032

WASHER

25

07095-00526

CUSHION

26

08034-20823

BAND
