Запчасти Komatsu PC45MR-1 МОТОР ХОДА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22N-60-11122

TRAVEL MOTOR ASS'Y

|1

TZ596B1000-01

FINAL DRIVE ASS'Y

1

TZ596B1001-00

HUB

|2

TZ573B1102-03

SPINDLE KIT

|2

TZ573B1132-03

SPINDLE ASS'Y

2

SPINDLE

3

FRANGE,HOLD

4

TZ550A1019-00

BOLT,REAMER

|5

TZ573B1104-02

RV GEAR ASS'Y

|5

TZ573B1204-02

RV GEAR KIT

5

RV GEAR,A

6

RV GEAR,B

7

TZ510B1009-00

SHAFT,CRANK

8

TZ310B1022-01

BEARING

9

TZ850A1023-00

BEARING,NEEDLE

10

TZ512B1006-01

GEAR,INPUT

|10

TZ512B1107-00

SPUR GEAR KIT (3 PIECES)

11

SPUR GEAR

12

TZ510B1008-01

COVER

13

TZ550A1014-00

PIECE,DISTANCE

14

TZ573B1017-00

PIN

15

TZ550A1018-00

RING

16

TZ310B1013-00

SNAP RING KIT (12 KINDS)

17

TZ573B1021-00

BEARING

18

04064-01510

RING,SNAP

19

04064-02212

RING,SNAP

20

07000-11007

O-RING (K1)

21

07000-05200

O-RING (K1)

22

TZJW1516-G26-7

O-RING (K1)

23

TZES100-178-B

SEAL,FLOATING (K1)

24

TZGM3-8

PLUG

K-1

TZ573B9000-00

SERVICE KIT

|K

07000-11007

O-RING

|K

07000-05200

O-RING

|K

TZJW1516-G26-7

O-RING

|K

TZES100-178-B

SEAL,FLOATING

|K

TZ15Z-17-35-8

SEAL,OIL

|K

TZ571B2035-01

O-RING

|K

TZJB2401-P22-9

O-RING

|K

07000-12012

O-RING

|K

TZ571B2039-01

O-RING

|K

TZ571B2078-01

O-RING
