Запчасти Komatsu PC450LCHD-8 БЫСТРОСЪЕМН. МЕХ-М ЛИНИИ (PPC ТРУБЫ) ( АКТУАТОР) (№K-) H ГИДРАВЛИКА

1

02760-002A3

HOSE

2

02760-00203

HOSE

3

02760-002A7

HOSE 750MM

4

02760-00208

HOSE 800MM

5

20Y-62-22840

BAND BLACK, BLACK

6

20Y-62-22860

BAND BROWN, BROWN

7

02760-00213

HOSE

8

207-62-72640

HOSE 1400MM

9

20Y-62-22790

BAND RED, RED

10

02760-00205

HOSE

11

04435-51512

CLIP

12

195-01-16261

COLLAR

13

01011-81235

BOLT

14

01643-31232

WASHER

15

04434-52512

CLIP

16

08034-20519

BAND

17

208-62-72570

HOSE 1200MM

18

208-62-72580

HOSE 1700MM

19

20Y-62-22810

BAND YELLOW

20

08034-20519

BAND

21

208-62-72570

HOSE 1200MM

22

208-62-72580

HOSE 1700MM

23

20Y-62-22840

BAND BLACK, BLACK

24

20Y-62-22860

BAND BROWN, BROWN

25

08034-20519

BAND

26

08034-20310

BAND

27

11Y-62-12160

ELBOW

28

07002-11423

O-RING

29

02896-11008

O-RING

30

20Y-62-43430

BLOCK

31

20Y-62-43450

PLATE

32

01010-80830

BOLT

33

01643-30823

WASHER

34

20Y-62-22271

ELBOW

35

201-60-11390

O-RING

36

20Y-62-19560

O-RING

37

14X-43-14840

ELBOW

38

201-60-11390

O-RING

39

20Y-62-19560

O-RING

40

07002-11423

O-RING

41

206-06-61130

SWITCH

42

08034-20536

BAND
