Запчасти Komatsu PC450LCHD-8 ОХЛАЖД-Е (РАДИАТОР И РАМА) (№K-) C СИСТЕМА ОХЛАЖДЕНИЯ

1

208-03-75111

CORE ASSEMBLY

|1

208-03-75110

CORE ASSEMBLY

2

20Y-03-22110

CAP

3

205-03-71230

HOSE

4

20Y-03-11330

CLIP

5

205-03-62660

PLUG

6

07000-11007

O-RING

7

208-03-75931

SEAL

|7

208-03-75930

SEAL

8

208-03-75940

SEAL

9

208-03-71840

SEAL

10

208-03-76490

BRACKET

11

01010-81235

BOLT

12

01643-31232

WASHER

13

14X-03-51621

CUSHION

14

14X-03-51640

SPACER

15

14X-03-51770

WASHER

16

01010-81055

BOLT

17

195-03-41380

CUSHION

18

207-03-75590

PLATE

19

01010-81050

BOLT

20

01643-31032

WASHER

21

208-03-75580

SEAL

22

208-03-75590

SEAL

23

208-03-77110

FRAME

24

208-03-77120

FRAME

25

208-03-76641

FRAME

|25

208-03-76640

FRAME

26

01010-81225

BOLT

27

01643-31232

WASHER

28

208-03-77380

FRAME

29

01010-81030

BOLT

30

01643-31032

WASHER

31

01010-81020

BOLT

32

01643-31032

WASHER

33

22B-03-12590

CUSHION

34

208-03-71380

CUSHION

35

208-03-77370

SEAL

36

208-03-77270

SEAL

37

208-03-77290

SEAL

38

208-03-77330

SEAL

39

208-03-71821

SEAL

40

208-03-75920

SEAL

41

208-03-75680

SEAL

42

208-03-75690

SEAL

43

208-03-76370

BRACKET

44

01010-81225

BOLT

45

01643-31232

WASHER

46

207-03-71680

STAY

47

01010-81235

BOLT

48

01643-31232

WASHER
