Запчасти Komatsu PC450LCHD-8 ОСНОВН. НАСОС (/) (№K8-) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

1

708-2H-00450

PUMP ASSEMBLY

1

708-2H-01450

PUMP SUB ASSEMBLY

1

708-2H-32110

SHAFT

2

708-1H-22150

BEARING

3

708-17-05010

WASHER KIT

3

WASHER 3.0MM

3

WASHER 3.1MM

3

WASHER 3.2MM

4

708-17-12780

RING, SNAP

5

708-2H-22570

SEAL, OIL

6

708-2H-22160

SPACER

7

04065-08225

RING, SNAP

8

708-2H-04750

CYLINDER BLOCK ASSEMBLY

8

BLOCK, CYLINDER

9

PLATE, VALVE

10

708-18-13230

PIN

11

04065-05820

RING

12

708-2H-33140

SEAT

13

708-2H-33150

SPRING

14

708-2H-23141

SEAT

15

708-2H-23350

GUIDE, RETAINER

16

708-2H-23360

PIN

17

708-2H-33343

RETAINER, SHOE

18

708-2H-33311

PISTON SUB ASSEMBLY

19

708-2H-04690

CRADLE SUB ASSEMBLY

19

CRADLE

20

CAM, ROCKER

21

04020-01434

PIN, DOWEL

22

07000-B1009

O-RING

23

01252-61235

BOLT
