Запчасти Komatsu PC450LC-8R ЗАПРАВОЧН.LING НАСОС (№7-) ЗАПРАВОЧН.LING НАСОС, EXTREMELY BAD ТОПЛИВН. И ПЛОХ. ТОПЛИВО ARRANGEMENT СПЕЦ-Я. ВОДН.+DUST

1

20Y-04-K2082

Pump

2

20Y-04-K2450

Valve Assembly

3

20Y-04-K2351

Hose

4

208-04-75460

Hose

5

208-04-75450

Hose

6

22B-04-K1130

Nipple

7

22B-04-K1140

Coupling

8

22B-04-K1150

Coupling

9

22B-04-K1160

Plug

10

22B-04-K1170

Plug

11

205-04-K1370

Washer, Seal

12

208-04-75440

Bracket

13

01010-80620

Bolt

14

01643-30623

Washer

15

01010-81225

Bolt

16

01643-31232

Washer

17

01010-81225

Bolt

18

01643-31232

Washer

19

07289-00035

Clamp

20

208-04-75430

Bracket

21

01010-81235

Bolt

22

01643-31232

Washer

23

207-04-75410

Bracket

24

01010-81225

Bolt

25

01643-31232

Washer

26

07289-00035

Clamp

27

07289-00035

Clamp

28

113-899-7950

Clip

29

01010-81260

Bolt

30

01643-31232

Washer

31

113-899-7950

Clip

32

208-04-75410

Bracket

33

207-06-71540

Switch Assembly

34

01010-80616

Bolt

35

01643-30623

Washer

36

208-06-71550

Wiring Harness

37

04434-51412

Clip

38

08034-20519

Band
