Запчасти Komatsu PC450LC-8R ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/) (№7-78) ПОРШЕНЬ НАСОС

|$0

708-2H-00027

Pump Assembly

|$1

708-2H-01027

Pump Subassembly

1

708-2H-34150

Slider

1

708-2H-03411

Valve Assembly

1

708-2H-03022

Piston Assembly

2

Piston

3

Plug

4

708-2G-15320

Seal

5

708-2H-15310

Plug

6

708-2L-35760

Ball

7

708-2L-35770

Plug

8

708-2L-35690

Seal

9

708-2L-35170

Pin

10

708-3M-15670

Spool

11

708-2G-15290

Retainer

12

708-2G-15140

Seat

13

708-2H-15330

Spring

14

708-2H-15320

Spring

15

708-2G-15151

Seat

16

708-2H-15340

Spring

17

708-2G-14340

Screw

18

07000-B3038

O-ring

19

708-2G-15230

Ring, Back-up

20

708-2G-15260

Seal

21

708-2G-15240

Plug

22

07000-B2012

O-ring

23

07000-B2050

O-ring

24

708-2G-15310

Ring, Back-up

25

708-2L-44161

Cover

26

01580-10806

Nut

27

708-2L-35540

Nut

28

708-2G-15330

Ring, Wear

29

01252-61645

Bolt, Hexagon Socket Head
