Запчасти Komatsu PC450LC-8R РУКОЯТЬ, ЦИЛИНДР КОВША (№7-) РУКОЯТЬ, MM, TURKEY

|$0

707-01-0F821

Cylinder Assembly

1

707-13-16870

Cylinder

2

707-58-11810

Rod

3

707-76-10130

Bushing

4

07145-00100

Seal, Dust, (Kit : K11)

5

07020-00000

Fitting, Grease

6

707-76-10140

Bushing

7

208-70-73530

Seal, Dust, (Kit : K11)

8

07020-00000

Fitting, Grease

9

707-27-16580

Head

10

707-56-11740

Seal, Dust, (Kit : K11)

11

07179-13126

Ring, Snap

12

707-52-90851

Bushing

13

707-51-11030

Packing, Rod, (Kit : K11)

14

707-51-11640

Ring, Buffer, (Kit : K11)

15

707-35-91640

Ring, Back-up, (Kit : K11)

16

07000-15150

O-ring, (Kit : K11)

17

01010-82085

Bolt

18

707-88-75310

Washer

19

707-75-11040

Ring, Snap

20

707-36-16580

Piston

21

707-44-16180

Ring, Piston, (Kit : K11)

22

707-39-16120

Ring, Wear, (Kit : K11)

23

707-44-16910

Ring

24

07000-15100

O-ring, (Kit : K11)

25

07001-05100

Ring, Back-up, (Kit : K11)

26

01310-01216

Screw

27

707-86-12580

Tube

28

707-86-12570

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-ring, (Kit : K11)

32

707-88-25390

Bracket

33

07372-21240

Bolt

34

01643-51232

Washer

35

707-88-10150

Clamp

36

01010-81245

Bolt

37

01643-31232

Washer

38

707-88-33040

Cap

39

07371-31049

Flange, Split

40

07372-21035

Bolt

41

01643-51032

Washer
