Запчасти Komatsu PC450LC-8K HIGH REACH DEMOLITION DIG СТРЕЛА БЫСТРОСЪЕМН. МЕХ-М ТРУБЫ (№K87-) TABLE OF CONTENTS PC-8 ВЫС. REACH РАЗРУШ. ЗДАНИЙ

1

206-62-KC330

CONNECTOR

2

206-62-KB880

UNION

3

207-62-KB471

SEAL

4

02896-11008

O-RING

5

02777-00224

HOSE

6

08034-20414

BAND

7

21P-62-K3240

BAND (RED)

8

21P-62-K3250

BAND (YELLOW)

9

21P-62-K3260

BAND (BLUE)

10

21P-62-K3280

BAND (BLACK)

11

21P-62-K3310

BAND (BROWN)

12

207-62-KH810

BAND (GREY)

13

208-62-KC840

TUBE

14

208-62-KC850

TUBE

15

02896-11008

O-RING

16

20Y-62-K5640

BRACKET

17

207-62-K5320

CLAMP

18

01010-81025

BOLT

19

01643-31032

WASHER

20

07283-53444

SEAT

21

07283-33450

CLIP

22

01643-31032

WASHER

23

01597-01009

NUT

24

20Y-62-K5690

BRACKET

25

20Y-62-K5780

CLAMP

26

07283-53444

SEAT

27

07283-33450

CLIP

28

01643-31032

WASHER

29

01597-01009

NUT

30

01010-81025

BOLT

31

01643-31032

WASHER

32

208-62-75340

BRACKET

33

208-62-75360

BRACKET

34

07283-33450

CLIP

35

07283-53444

SEAT

36

01643-31032

WASHER

37

01597-01009

NUT

38

20Y-62-K5780

CLAMP

39

01010-81025

BOLT

40

01643-31032

WASHER
