Запчасти Komatsu PC450LC-8K HIGH REACH DEMOLITION 1-Я СТРЕЛА В СБОРЕ TABLE OF CONTENTS PC-8 ВЫС. REACH РАЗРУШ. ЗДАНИЙ
104
103
154
105
106
107
108
66
65
64
63
62
61
60
56
57
67
68
93
58
59
52
53
54
55
50
51
46
47
48
49
42
43
44
45
109
118
117
116
115
114
113
112
111
110
1
16
13
14
15
11
12
8
10
101
100
99
2
3
4
5
6
7
144
143
27
26
25
24
23
29
30
34
35
31
32
33
36
37
38
39
40
41
90
28
9
102
79
78
77
76
75
89
84
85
83
82
81
80
74
73
86
71
72
88
87
70
69
92
91
94
95
96
97
98
140
139
141
142
155
156
157
22
21
20
19
18
17
148
147
146
145
150
149
153
152
151
137
138
136
135
134
126
125
124
123
122
133
132
131
130
129
128
127
121
120
119
1
208-70-KD283
No. 1 BOOM
|1
208-70-KD282
No. 1 BOOM
|1
208-70-KD281
No. 1 BOOM
|1
208-70-KD280
No. 1 BOOM
2
KV-B240-2520
TUBE
3
KV-X5X0-7070
NIPPLE
4
02753-00623
HOSE
5
01010-81016
BOLT
6
01643-31032
WASHER
7
08036-01014
CLIP
8
KV-B240-2510
TUBE
9
205-70-51390
NIPPLE
10
208-70-62190
HOSE
11
707-01-18650
BOOM CYLINDER LH
12
707-01-18660
BOOM CYLINDER RH
13
KV-1B23-3571
PLATE
14
01010-80812
BOLT
15
01643-30823
WASHER
16
KV-1B27-2320
SEAT
17
207-06-31445
WIRING HARNESS
18
203-06-56570
BAND
19
20Y-06-K2760
WORK LAMP ASSY
20
KV-B121-1510
GUARD
21
01010-81430
BOLT
22
01643-31445
WASHER
23
208-62-KC910
TUBE
23
208-62-KB970
TUBE
24
21P-62-K3270
BAND (WHITE)
25
07371-31049
FLANGE
26
07372-21035
BOLT
27
01643-51032
WASHER
28
07000-13035
O-RING
29
208-62-KC920
TUBE
29
208-62-KB960
TUBE
30
21P-62-K3280
BAND (BLACK)
31
208-62-KB911
TUBE
32
07000-13022
O-RING
33
07371-30500
FLANGE
34
01010-80830
BOLT
35
01643-50823
WASHER
36
208-62-KB980
TUBE
37
207-62-KH810
BAND (GREY)
38
208-62-KB830
TUBE
39
208-62-86140
VALVE
40
07000-13024
O-RING
41
208-62-KB920
TUBE
42
208-62-85961
TUBE
43
07000-13035
O-RING
44
07372-21040
BOLT
45
01643-51032
WASHER
46
208-62-85970
TUBE
47
07000-13035
O-RING
48
01010-81060
BOLT
49
01643-31032
WASHER
50
208-62-KB990
TUBE
51
21P-62-K3310
BAND (BROWN)
52
207-62-52350
CLAMP
53
01010-81235
BOLT
54
01643-31232
WASHER
55
205-62-73431
SEAT
56
207-62-54780
CLAMP
57
01010-81235
BOLT
58
01643-31232
WASHER
59
205-62-73431
SEAT
60
205-70-51380
ELBOW
61
209-72-16550
HOSE
62
07020-00675
FITTING
63
207-62-52350
CLAMP
64
01010-81235
BOLT
65
01643-31232
WASHER
66
205-62-73431
SEAT
67
208-62-86120
TUBE
68
208-62-86110
TUBE
69
208-62-KB950
TUBE
70
21P-62-K3260
BAND (BLUE)
71
208-62-KB930
TUBE
72
21P-62-K3250
BAND (YELLOW)
73
208-62-KC930
TUBE
73
208-62-KB940
TUBE
74
21P-62-K3240
BAND (RED)
75
208-62-KB890
TUBE
76
07000-13022
O-RING
77
07371-30500
FLANGE
78
01010-80830
BOLT
79
01643-50823
WASHER
80
208-62-KC111
TUBE
81
21P-62-K3290
BAND (GREEN)
82
07371-31049
FLANGE
83
07372-21035
BOLT
84
01643-51032
WASHER
85
07000-13035
O-RING
86
208-62-85980
TUBE
87
208-62-86130
VALVE
88
07000-13029
O-RING
89
02756-00508
HOSE
90
02756-00506
HOSE
91
KV-X5X0-1900
ELBOW
92
07214-51013
CONNECTOR
93
07020-00000
FITTING
94
07214-51013
CONNECTOR
95
KV-B240-2530
TUBE
96
08036-01014
CLIP
97
01010-81016
BOLT
98
01643-31032
WASHER
99
04434-51810
CLIP
100
01010-81020
BOLT
101
01643-31032
WASHER
102
02756-00219
HOSE
103
208-70-71541
SPACER
104
07145-00120
SEAL
105
208-70-71531
SPACER
106
208-70-71541
SPACER
107
208-70-71551
SPACER
108
208-70-71561
SPACER
109
208-70-71661
SPACER
110
207-970-7310
CLAMP
111
01010-81235
BOLT
112
01643-31232
WASHER
113
208-970-7161
BRACKET
114
01010-81260
BOLT
115
01643-31232
WASHER
116
207-62-31330
CLAMP
117
01010-81260
BOLT
118
01643-31232
WASHER
119
207-62-KG250
CLAMP
120
01010-81245
BOLT
121
01643-31232
WASHER
122
207-62-KG430
CLAMP
123
205-62-54622
SEAT
124
209-62-58520
SEAT
125
01010-81250
BOLT
126
01643-31232
WASHER
127
07094-10417
CLAMP
128
07095-00420
CUSHION
129
01010-81200
BOLT
130
07094-30417
CLAMP
131
07095-00420
CUSHION
132
01010-81295
BOLT
133
01643-31232
WASHER
134
01010-81245
BOLT
135
01643-31232
WASHER
136
01643-31232
WASHER
137
207-62-88690
CLAMP
138
208-62-85780
CUSHION
139
01010-81245
BOLT
140
01643-31232
WASHER
141
207-62-88880
CLAMP
142
208-62-85780
CUSHION
143
02756-00506
HOSE
144
02757-00506
HOSE
145
KV-B240-8080
HOSE
146
02781-00422
ELBOW
147
07002-12034
O-RING
148
02896-11012
O-RING
149
01010-81290
BOLT
150
01643-31232
WASHER
151
207-62-84221
CLAMP
152
01010-81265
BOLT
153
01643-31232
WASHER
154
208-70-71590
PIN
155
207-70-KJ980
BRACKET
156
01010-81225
BOLT
157
01643-31232
WASHER
