Запчасти Komatsu PC450LC-8K HIGH REACH DEMOLITION 1, 2, 3-Я СТРЕЛА ПАЛЕЦS И ВТУЛКАS TABLE OF CONTENTS PC-8 ВЫС. REACH РАЗРУШ. ЗДАНИЙ

1

208-70-KD280

NO.1 BOOM

2

208-70-KC532

NO. 2 BOOM

3

208-70-KC661

NO. 3 BOOM

4

07145-00120

SEAL

5

208-70-71510

BUSHING

6

206-70-K1680

BUSHING

7

KV-B240-6190

BUSHING

8

KV-B27-1151

BUSHING

9

208-70-71590

PIN

10

208-46-k2220

PLATE

11

01010-81645

BOLT

12

01643-31645

WASHER

13

208-70-31290

SPACER,0.8MM

|$14

208-70-51310

SPACER,1.5MM

14

208-70-61210

PIN

15

205-70-66580

PLATE

16

01010-81235

BOLT

17

01643-31232

WASHER

18

208-70-51320

SPACER,1.5MM

|$20

207-70-31340

SPACER,0.8MM

19

208-70-61860

PIN

20

208-70-31242

PLATE

21

207-70-13340

BOLT

22

01580-12419

NUT

23

208-70-71561

SPACER

24

208-70-71571

SPACER

25

KV-B27-1140

PIN

26

205-70-61560

PLATE

27

1010-82045

BOLT

28

01643-32060

WASHER

29

208-70-31310

SPACER

30

KV-1B27-1160

HOLDER

31

01010-82055

BOLT

32

01643-32060

WASHER

33

208-70-61220

PIN

34

205-70-66580

PLATE

35

01010-81235

BOLT

36

01643-31232

WASHER

37

207-70-11360

SPACER

38

KV-B240-6170

PIN

39

205-70-71310

PLATE

40

01024-81240

BOLT

41

07020-00675

FITTING

42

KV-B240-6180

PLATE

43

01010-82055

BOLT

44

01643-32060

WASHER

45

206-70-55250

SPACER

46

208-70-81580

SPACER
