Запчасти Komatsu PC450LC-8K HIGH REACH DEMOLITION ГИДР. БАК. (ДЛЯ КЛАПАНА ПЕРЕГРУЗКИ) TABLE OF CONTENTS PC-8 ВЫС. REACH РАЗРУШ. ЗДАНИЙ

1

208-60-75110

TANK

2

203-60-31100

ELBOW ASSEMBLY

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-12434

O-RING

6

207-62-72171

ELBOW

7

07002-12434

O-RING

8

02896-11018

O-RING

9

02782-10522

ELBOW

10

07002-12434

O-RING

11

02896-11015

O-RING

12

19M-61-35140

TEE

13

07002-12034

O-RING

14

02896-11009

O-RING

15

207-62-72110

UNION

16

07002-13334

O-RING

17

207-62-64740

O-RING

18

02782-10422

ELBOW

19

07002-12034

O-RING

20

02896-11012

O-RING

21

02783-10210

ELBOW

22

07002-11423

O-RING

23

02896-11008

O-RING

24

208-60-71122

ELEMENT

25

07069-25400

STRAINER

26

208-60-71160

VALVE ASSEMBLY

27

07069-34075

SPRING

28

208-60-71130

PLATE

29

07000-15210

O-RING

30

01010-81225

BOLT

31

01643-31232

WASHER

|32

208-60-71140

STRAINER ASSEMBLY

32

208-60-71150

ROD ASSEMBLY

33

12R-60-11230

SPRING

34

20Y-60-21320

HOLDER

35

22B-60-11160

STRAINER

36

208-60-61190

COVER

37

07000-15180

O-RING

38

01010-81225

BOLT

39

01643-31232

WASHER

40

198-60-55510

BREATHER

41

17A-60-11310

CAP ASSEMBLY

42

20Y-60-21470

ELEMENT

43

208-60-71180

FILLER NECK

44

20Y-60-21340

GASKET

45

01252-70516

BOLT

46

01601-20513

WASHER

47

07285-00155

CLAMP

48

07270-61431

TUBE

49

07056-10045

STRAINER

50

04065-04718

RING

51

208-60-71250

SHEET

52

208-60-75240

SHEET

53

01010-81635

BOLT

54

01643-31645

WASHER

55

195-03-11570

SHIM

56

134-03-61410

BAND
