Запчасти Komatsu PC450LC-8K HIGH REACH DEMOLITION ГИДРАВЛALLY РЕГУЛИР. ГУСЕНИЦЫРАМА (7 MM SHOES) - HWG TABLE OF CONTENTS PC-8 ВЫС. REACH РАЗРУШ. ЗДАНИЙ
№
Артикул
Название
Примечание
Количество
1
208-30-KB340
TRACK FRAME
4
208-32-03400
TRACK SHOE ASSY
5
208-30-KB310
CARRIER ROLLER
6
208-30-00310
TRACK ROLLER
7
208-30-74500
FRONT IDLER
8
208-30-KB320
VALVE
9
208-27-61210
SPROCKET
10
208-27-00243
GEAR MOTOR AND SPROCKET
11
207-27-K1130
BOLT
12
205-30-72170
PLATE
13
20Y-30-29170
BOLT
14
20Y-30-29180
WASHER
15
703-10-33620
SWIVEL JOINT
16
208-63-KA230
CYLINDER
17
208-60-KA110
VALVE
18
208-60-KA120
VALVE
19
208-30-KB370
BLOCK
20
208-30-KB380
PIN
21
208-30-KB390
PIN
22
208-30-KB460
SPACER
23
208-30-KB470
SPACER
24
208-30-KB410
PIN
25
208-30-KB450
WEDGE
26
208-30-KB440
KEY
27
208-30-KB630
PLUG
28
208-30-KB430
TRACK GUIDE
29
208-30-KB420
FOOT BOARD
30
208-30-KB750
FOOT BOARD
31
208-30-KB820
BOLT
32
208-30-KB480
BOLT
33
207-30-KC360
WASHER
34
208-30-KB510
BOLT
35
208-30-KB520
WASHER
36
208-30-KB570
BOLT
37
208-30-KB880
NUT
38
208-30-KB590
BOLT
39
208-30-KB610
WASHER
40
208-30-KB640
BOLT
41
208-30-KB890
WASHER
42
208-30-KB910
BOLT
43
208-30-KB670
BOLT
44
208-30-KB690
BOLT
45
208-30-KB920
WASHER
46
208-30-KB720
BOLT
47
208-30-KB730
BOLT
48
208-30-KB740
BOLT
49
207-30-KB940
FITTING
50
207-30-KB930
PLUG
51
208-30-KB760
BOLT
52
208-30-KB770
BOLT
53
208-30-KB780
BOLT
54
208-30-KC370
BOLT
54
208-30-KB790
BOLT
55
208-30-KC380
NUT
55
208-30-KB810
NUT
56
208-30-KB830
PLUG
57
208-30-KB940
BOLT
58
208-30-KB950
BOLT
59
208-30-KB840
WASHER
60
208-30-KB850
BOLT
61
208-30-KB960
WASHER
62
208-30-KB980
WASHER
63
207-30-KC650
CRANK CASE
64
208-30-KB990
BOLT
65
208-30-KC110
BOLT
66
208-30-KB620
CLAMP
67
208-30-KB710
PLATE
68
208-30-KC120
CLAMP
69
208-30-KB660
ANTI WEAR PLATE
70
208-30-KB680
PLATE
71
208-30-KC210
CRANK CASE COVER,FRONT L.H.
72
208-30-KC140
CRANK CASE COVER,BACK L.H.
73
208-30-KC230
CRANK CASE COVER,FRONT AND BACK R.H.
Выбрано товаров: 73
