Запчасти Komatsu PC450LC-8 ОСНОВ. MACHINE АВТОМАТИЧ. СМАЗ. ЧАСТИ (№K-) G АВТОМАТИЧ. СМАЗ. СИСТЕМА

1

207-54-K3570

PUMP

2

207-54-K3710

FITTING

3

207-54-K3720

FITTING

4

208-06-K1290

WIRING HARNESS

5

208-70-K2930

HOSE

6

208-70-K2940

HOSE

7

208-70-K2950

HOSE

8

207-54-K1040

HOSE

9

20Y-62-K7580

FITTING

10

20Y-62-K7580

FITTING

11

20Y-62-K7910

MONITOR

12

207-06-K2540

WIRING HARNESS

13

207-54-K1020

HOSE

14

01010-81020

BOLT

15

01643-31032

WASHER

16

07326-10201

ADAPTER

17

207-70-K4351

BLOCK

|17

207-70-K4350

BLOCK

18

07020-00000

FITTING

19

04435-52112

CLIP

20

195-33-11220

SPACER

21

01010-81255

BOLT

22

01643-31232

WASHER

23

01010-81260

BOLT

24

01643-31232

WASHER

25

01010-81225

BOLT

26

01643-31232

WASHER

27

208-62-K3460

BRACKET

|27

207-70-K3251

BRACKET

|27

207-70-K3250

BRACKET

28

04434-51912

CLIP

29

04434-51212

CLIP

30

08034-20536

BAND

31

20Y-70-K6030

BRACKET

32

20Y-01-K2220

PLATE

33

01010-80845

BOLT

34

01023-10416

SCREW

35

08034-00414

BAND

36

01640-20408

WASHER

37

01580-10403

NUT

38

01245-00820

SCREW

39

01643-70823

WASHER

40

08193-21012

CLIP

41

04434-51012

CLIP

42

04435-52112

CLIP

43

01010-81225

BOLT

44

01643-31232

WASHER
