Запчасти Komatsu PC450LC-8 ОХЛАЖД-Е (COVER) (№K-K9) C СИСТЕМА ОХЛАЖДЕНИЯ

Схема запчастей Komatsu PC450LC-8 - ОХЛАЖД-Е (COVER) (№K-K9) C СИСТЕМА ОХЛАЖДЕНИЯ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
29
29
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
29
29

Артикул

Название

Примечание

Количество

1

208-03-75620

COVER

2

208-03-71580

SEAL

3

208-03-71610

SEAL

4

208-03-71670

SEAL

5

208-03-75630

SEAL

6

208-03-75640

SEAL

7

01010-81225

BOLT

8

01643-31232

WASHER

9

208-03-75650

COVER

10

208-03-75660

SEAL

11

208-03-75840

SEAL

12

01010-81225

BOLT

13

01643-31232

WASHER

14

208-03-75711

COVER

15

208-03-75721

SEAL

16

01010-81225

BOLT

17

01643-31232

WASHER

18

208-03-75731

COVER

19

208-03-75741

SEAL

20

01010-81225

BOLT

21

01643-31232

WASHER

22

208-03-75751

COVER

23

208-03-75761

SEAL

24

01010-81225

BOLT

25

01643-31232

WASHER

26

208-03-58310

HOSE 600MM

27

206-03-43340

CLIP

28

01010-81640

BOLT

29

01643-31645

WASHER

1

208-03-75620

COVER

2

208-03-71580

SEAL

3

208-03-71610

SEAL

4

208-03-71670

SEAL

5

208-03-75630

SEAL

6

208-03-75640

SEAL

7

01010-81225

BOLT

8

01643-31232

WASHER

9

208-03-75650

COVER

10

208-03-75660

SEAL

11

208-03-75840

SEAL

12

01010-81225

BOLT

13

01643-31232

WASHER

14

208-03-75711

COVER

15

208-03-75721

SEAL

16

01010-81225

BOLT

17

01643-31232

WASHER

18

208-03-75731

COVER

19

208-03-75741

SEAL

20

01010-81225

BOLT

21

01643-31232

WASHER

22

208-03-75751

COVER

23

208-03-75761

SEAL

24

01010-81225

BOLT

25

01643-31232

WASHER

26

208-03-58310

HOSE 600MM

27

206-03-43340

CLIP

28

01010-81640

BOLT

29

01643-31645

WASHER

Выбрано товаров: 58
