Запчасти Komatsu PC450LC-8 A-BL ТУРБОНАГНЕТАТЕЛЬ KTR9-E ВНУТР. ЧАСТИ ДВИГАТЕЛЬ

|$0

6506-21-5020

TURBOCHARGER ASSEMBLY

|$1

6506-21-5910

CORE ASSEMBLY

1

NSS

ROTOR, TURBINE

2

NSS

PLATE, COLLAR

3

NSS

SPACER, COLLAR

4

NSS

FLINGER

5

NSS

IMPELLER, BLOWER

6

NSS

NUT, LOCK

7

NSS

BEARING, JOURNAL

8

NSS

BEARING, THRUST

9

NSS

RING, SEAL TURBINE

10

NSS

RING, SEAL TURBINE

11

NSS

SHIELD, HEAT

12

NSS

HOUSING, CENTER

13

NSS

PIN, DOWEL

14

NSS

O-RING

15

NSS

INSERT

16

NSS

RING, SNAP

17

6506-21-4230

HOUSING, TURBINE

18

6505-11-0520

PLATE

19

01020-01016

BOLT

20

6506-21-2030

HOUSING, BLOWER

21

6501-11-1721

V-BAND

22

6505-99-9011

PLATE, NAME

23

04418-02550

SCREW
