Запчасти Komatsu PC450LC-8 A-AS ТРУБОПРОВОД ВПУСКА ВОЗДУХА И СОЕДИН-Е ДВИГАТЕЛЬ

1

6251-11-4110

MANIFOLD, AIR INTAKE

2

01436-01030

BOLT

3

01435-01080

BOLT

4

6251-11-4250

COVER

5

6251-11-4260

GASKET

6

01435-01025

BOLT

7

6150-13-4810

GASKET

8

6261-81-2700

SENSOR ASSEMBLY

|$8

6261-81-2710

SENSOR, BOOST PRESSURE

|$9

6261-81-2720

O-RING

9

01435-00616

BOLT

10

6560-61-7300

SENSOR ASSEMBLY

|$12

6560-61-7310

SENSOR, BOOST TEMPERATURE

|$13

6735-21-1930

O-RING

11

6251-11-4320

CONNECTOR, AIR INLET

12

6251-11-4830

GASKET

13

600-815-3812

HEATER, RIBBON

14

01435-01070

BOLT

15

01435-01080

BOLT

16

07042-A0108

PLUG

17

6251-81-4520

PLATE

18

01643-31032

WASHER

19

6251-11-7210

HOUSING, AIR JUNCTION

20

01436-01060

BOLT

21

01435-01040

BOLT

22

6251-11-9730

NOZZLE, VENTURI

23

01437-10816

BOLT

24

6251-11-7410

CONNECTOR, UPPER

25

6251-11-7450

GASKET

26

01435-01035

BOLT

27

6251-11-4820

GASKET

28

6251-11-4410

BRACKET

29

01435-01045

BOLT

30

6210-11-5820

SPACER
