Запчасти Komatsu PC450LC-8 K-8B КАБИНА КОНДИЦ. ВОЗДУХА BREAKDOWN OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-810-1211

AIR CONDITIONER

1

ND245450-5831

CASE, COOLING

2

ND245450-5840

CASE, COOLING

3

ND116576-3810

PLATE

4

ND116576-3820

PLATE

|$5

ND446010-3132

EVAPORATOR ASSEMBLY, PART

5

ND446600-0991

EVAPORATOR ASSEMBLY

6

ND949142-0020

O-RING

7

ND949142-0030

O-RING

8

ND447500-2750

VALVE, EXPANSION

9

ND949046-3100

BOLT

10

ND146657-8841

PACKING

11

ND146657-9811

PACKING

12

ND146657-8850

PACKING

13

ND445021-3941

PLUG

14

ND116140-0050

CORE SUBASSEMBLY, HEATER

15

ND116660-7570

DOOR SUBASSEMBLY

16

ND116650-6850

DOOR SUBASSEMBLY

17

ND116780-2481

LEVER SUBASSEMBLY, LINK

18

ND116780-2491

LEVER SUBASSEMBLY, LINK

19

ND116780-2501

LEVER SUBASSEMBLY, LINK

20

ND116780-2510

LEVER SUBASSEMBLY, LINK

21

ND116781-3000

LEVER

22

ND116780-3130

LEVER SUBASSEMBLY, LINK

23

ND116662-7670

SHAFT

24

ND116662-7681

SHAFT

25

ND116576-3852

PLATE

26

ND116576-3862

PLATE

27

ND063800-0300

SERVO MOTOR ASSEMBLY

28

ND017231-0700

CLAMP

29

ND077500-5890

THERMISTOR ASSEMBLY

30

ND246790-2060

CLAMP

31

ND116780-3920

LEVER SUB ASSEMBLY, LINK

32

ND146667-0440

PACKING

33

ND077800-0750

POWER TRANSISTOR

34

ND146340-0560

BOX ASSEMBLY

35

ND063600-4580

SERVO MOTOR ASSEMBLY

36

ND077500-5650

THERMISTOR ASSEMBLY

37

ND146657-8860

PACKING

38

ND116340-7350

MOTOR ASSEMBLY, FAN

39

ND949008-0460

SCREW, TAPPING

40

ND949008-0330

SCREW, TAPPING

41

ND949001-1730

SCREW, TAPPING

42

ND246470-4311

HARNESS SUBASSEMBLY, WIRE

43

ND93950-05003

FUSE

44

ND116662-8320

SHAFT
