Запчасти Komatsu PC450LC-8 H-A ГИДР. БАК. ГИДРАВЛИКА
37
35
27
36
55
28
33
34
25
38
30
26
42
39
31
43
40
24
47
41
23
29
44
46
49
22
45
32
21
18
20
19
51
50
2
3
17
2
15
6
8
16
7
11
14
12
13
1
56
9
10
54
53
48
5
54
52
53
4
52
1
208-60-75111
TANK
2
203-60-31100
ELBOW
3
203-60-31160
TUBE
4
07044-12412
PLUG
5
07002-12434
O-RING
6
02783-10628
ELBOW
7
07002-12434
O-RING
8
02896-11018
O-RING
9
02782-10315
ELBOW
10
07002-12034
O-RING
11
02896-11009
O-RING
12
207-62-72110
UNION
13
07002-13334
O-RING
14
207-62-64740
O-RING
15
02782-10422
ELBOW
16
07002-12034
O-RING
17
02896-11012
O-RING
18
02783-10210
ELBOW
19
07002-11423
O-RING
20
02896-11008
O-RING
21
208-60-71123
ELEMENT
22
07069-25400
STRAINER
23
208-60-71160
VALVE
24
07069-34075
SPRING
25
208-60-71130
PLATE
26
07000-15210
O-RING
27
01010-81225
BOLT
28
01643-31232
WASHER
|$28
208-60-71140
STRAINER
29
208-60-71150
ROD
30
12R-60-11230
SPRING
31
20Y-60-21320
HOLDER
32
22B-60-11160
STRAINER
33
208-60-61190
COVER
34
07000-15180
O-RING
35
01010-81225
BOLT
36
01643-31232
WASHER
38
17A-60-11310
CAP
39
20Y-60-21470
ELEMENT
40
208-60-71181
FILLER NECK
41
20Y-60-21340
GASKET
42
01252-70516
BOLT
43
01601-20513
WASHER
44
07285-00200
CLIP, HOSE
45
07261-21431
HOSE
46
07056-10045
STRAINER
47
04065-04718
RING
48
208-60-71250
SHEET
49
208-60-75240
SHEET
50
20Y-00-42110
PLATE
51
21M-00-21290
PLATE
52
01010-81635
BOLT
53
01643-31645
WASHER
54
195-03-11570
SHIM, 1.0 MM
55
134-03-61410
BAND
56
208-60-75120
TRIM
