Запчасти Komatsu PC450LC-7 ОПОРНЫЙ КАТОК (ДВУБОРТН.)(№9-) ХОДОВАЯ

|$4

208-30-00211

TRACK ROLLER ASS'Y

|$5

208-30-00210

TRACK ROLLER ASS'Y

1

208-30-76110

ROLLER

1

208-30-56111

ROLLER

2

208-30-56130

SHAFT

3

207-30-53140

BUSHING

4

208-30-76140

COLLAR

4

208-30-56151

COLLAR

5

208-30-76150

COLLAR

5

208-30-56161

COLLAR

6

207-30-53160

PIN

|$18

208-30-00390

FLOATING SEAL ASS'Y

|$19

207-30-00101

FLOATING SEAL ASS'Y

7

SEAL

7

RING

8

O-RING

8

O-RING

9

208-30-56170

O-RING

10

20Y-30-16330

PLUG

|$30

208-30-00413

TRACK ROLLER AS

|$31

208-30-00412

TRACK ROLLER ASS'Y

11

208-30-76120

TRACK ROLLER

11

208-30-56212

ROLLER

12

208-30-56130

SHAFT

13

207-30-53140

BUSHING

14

208-30-76140

COLLAR

14

208-30-56151

COLLAR

15

208-30-76150

COLLAR

15

208-30-56161

COLLAR

16

207-30-53160

PIN

|$41

208-30-00390

FLOATING SEAL ASS'Y

|$42

207-30-00101

FLOATING SEAL ASS'Y

17

SEAL

17

RING

18

O-RING

18

O-RING

19

208-30-56170

O-RING

20

20Y-30-16330

PLUG

21

208-30-56180

BOLT

22

01643-32260

WASHER
