Запчасти Komatsu PC450LC-7-M1 ОСНОВН. НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2H-00022

PUMP ASS'Y

|1

708-2H-01022

PUMP SUB ASS'Y

1

708-2H-34150

SLIDER

|2

708-2H-03411

VALVE ASS'Y,PC

|2

708-2H-03022

PISTON ASS'Y,SERVO

2

PISTON,SERVO

3

SCREW

4

708-2G-15320

SEAL

5

708-2H-15310

PLUG

6

708-2L-35760

BALL

7

708-2L-35770

PLUG

8

708-2L-35690

SEAL

9

708-2L-35170

PIN

10

708-3M-15670

SPOOL

11

708-2G-15290

RETAINER

12

708-2G-15140

SEAT

13

708-2H-15330

SPRING

14

708-2H-15320

SPRING

15

708-2G-15151

SEAT

16

708-2H-15340

SPRING

17

708-2G-14340

SCREW

18

07000-B3038

O-RING

19

708-2G-15230

RING,BACK-UP

20

708-2G-15260

SEAL

21

708-2G-15240

PLUG

22

07000-B2012

O-RING

23

07000-B2050

O-RING

24

708-2G-15310

RING

25

708-2L-44161

COVER

26

01580-10806

NUT

27

708-2L-35540

NUT

28

708-2G-15330

RING,WIRE

29

01252-61645

BOLT
