Запчасти Komatsu PC450LC-6K ЦИЛИНДР СТРЕЛЫ(№K-K999) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

208-63-K2301

BOOM CYLINDER ASS'Y

|1

208-63-K2321

BOOM CYLINDER ASS'Y

1

208-63-53341

CYLINDER

2

208-70-K2250

BUSHING

|2

208-70-51390

BUSHING

3

07145-00100

SEAL,DUST

4

07020-00675

FITTING,GREASE

4A

07043-00108

PLUG

5

208-63-53120

ROD

6

208-70-51440

BUSHING

7

07145-00110

SEAL,DUST

8

707-71-31550

COLLAR

9

707-71-31181

COLLAR

10

07001-05155

RING,BACK-UP

11

07000-15155

O-RING

12

707-71-61100

PLUNGER

13

707-71-11150

RING

14

707-27-16620

HEAD

15

198-63-94170

SEAL,DUST

16

07179-13126

RING,SNAP

17

707-52-90860

BUSHING

18

707-51-11030

PACKING,ROD

19

707-51-11630

RING,BUFFER

20

07001-05155

RING,BACK-UP

21

07000-15155

O-RING

22

01010-62085

BOLT

23

707-88-75310

WASHER

24

707-36-16320

PISTON

25

707-40-16870

SPACER

26

01252-31450

BOLT

27

707-44-16180

RING,PISTON

28

707-39-16820

RING,WEAR

29

707-44-16910

RING

30

707-35-52930

RING,BACK-UP

31

07000-12090

O-RING

32

208-63-53171

TUBE,L.H.

|32

208-63-53271

TUBE,R.H.

33

01010-81060

BOLT

34

01643-51032

WASHER

35

07000-13035

O-RING

36

707-88-87110

BRACKET,L.H.

|36

707-88-87120

BRACKET,R.H.

37

707-88-95770

BAND

38

01010-81240

BOLT

39

01643-51232

WASHER

40

07283-23442

CLIP

41

01643-31032

WASHER

42

01599-01011

NUT

43

01010-81025

BOLT

44

01643-31032

WASHER
