Запчасти Komatsu PC450LC-6K ПРАВ. ДВЕРЬ (КАБИНА)(№K-) ЧАСТИ КОРПУСА

1

20Y-54-K7741

SHEET

2

207-54-K2380

SHEET

3

207-54-K2490

SEAL

4

20Y-54-K7430

SEAL

5

20Y-54-K7430

SEAL

6

207-54-K2350

SEAL

7

207-54-K2650

COVER

|7

207-54-K2312

COVER

|7

207-54-K2311

COVER

|7

207-54-K2310

COVER

8

20Y-54-K7450

HINGE (WELDED)

9

198-54-41982

LOCK ASS'Y (WELDED)

10

207-54-K2632

COVER

|10

207-54-K2631

COVER

|10

207-54-K2630

COVER

11

20Y-54-K7450

HINGE (WELDED)

12

198-54-41982

LOCK ASS'Y (WELDED)

13

205-54-53550

DOVE TAIL

14

01010-80612

BOLT

15

01643-30623

WASHER

16

208-54-K4440

FRAME,R.H.

17

20Y-54-K8010

BRACKET

|17

20Y-54-33170

BRACKET

18

01010-81230

BOLT

19

01643-31232

WASHER

20

205-54-51970

DOVE TAIL

21

01010-80616

BOLT

22

01643-30623

WASHER

23

20Y-54-K7421

PLATE

24

01010-81230

BOLT

25

01643-31232

WASHER

26

20E-54-K2230

BAR

27

01641-21016

WASHER

28

04050-13018

PIN

29

20Y-54-11611

STOPPER

30

01580-11008

NUT

31

207-54-K2340

PLATE

32

01010-81225

BOLT

33

01643-51232

WASHER

34

20E-54-K2230

BAR

35

01641-21016

WASHER

36

04050-13018

PIN

37

20Y-54-11611

STOPPER

38

01580-11008

NUT

39

01010-81225

BOLT

|39

01010-81235

BOLT

40

01643-31232

WASHER

41

20Y-54-33290

PLATE

42

01010-81230

BOLT

43

01643-31232

WASHER
