Запчасти Komatsu PC450LC-6K ПРАВ. ДВЕРЬ (КАБИНА)(№K-K999) ЧАСТИ КОРПУСА

1

207-54-K2310

COVER

2

20Y-54-28161

HINGE (WELDED)

3

198-54-41982

LOCK ASS'Y (WELDED)

4

20Y-54-K7413

COVER

5

20Y-54-K7450

HINGE (WELDED)

6

198-54-41982

LOCK ASS'Y (WELDED)

7

205-54-53550

DOVE TAIL

8

01010-80612

BOLT

9

01643-30623

WASHER

10

208-54-K2310

COVER,R.H.

11

20Y-54-33170

BRACKET

12

01010-81230

BOLT

13

01643-31232

WASHER

14

205-54-51970

DOVE TAIL

15

01010-80616

BOLT

16

01643-30623

WASHER

17

20Y-54-K7421

PLATE

18

01010-81230

BOLT

19

01643-31232

WASHER

20

20E-54-K2230

BAR

21

207-54-K2490

SEAL

22

20Y-54-K7430

SEAL

23

20Y-54-11611

STOPPER

24

01580-11008

NUT

25

207-54-K2340

PLATE

26

01010-81225

BOLT

27

01643-51232

WASHER

28

20E-54-K2230

BAR

29

20Y-54-K7430

SEAL

30

207-54-K2350

SEAL

31

20Y-54-11611

STOPPER

32

01580-11008

NUT

33

01010-81235

BOLT

34

01643-31232

WASHER

35

20Y-54-33290

PLATE

36

208-54-K2321

COVER,R.H.

37

01010-81230

BOLT

38

01643-31232

WASHER

39

01010-81230

BOLT

40

01643-31232

WASHER

41

20Y-54-K7741

SHEET

42

207-54-K2380

SHEET

43

208-54-K2330

SHEET

44

208-54-K2340

SHEET
