Запчасти Komatsu PC450LC-6K ЛЕВ. ДВЕРЬ (КАБИНА)(№K-K999) ЧАСТИ КОРПУСА

1

208-54-K2410

COVER

2

207-54-61160

SHEET

3

208-54-68480

SHEET

3A

207-54-K2450

HINGE (WELDED)

4

207-54-K2440

BRACKET

5

01010-81230

BOLT

6

01643-31232

WASHER

7

01010-81230

BOLT

8

01643-31232

WASHER

9

207-54-61181

PLATE

10

01010-81230

BOLT

11

01643-31232

WASHER

12

20Y-54-K7413

COVER

13

20Y-54-K7450

HINGE (WELDED)

14

198-54-41982

LOCK ASS'Y (WELDED)

15

205-54-53550

DOVE TAIL

16

01010-80612

BOLT

17

01643-30623

WASHER

18

208-54-K4250

FRAME

|18

208-54-K2610

FRAME

19

01010-81230

BOLT

20

01643-31232

WASHER

21

20Y-54-33170

BRACKET

22

205-54-51970

DOVE TAIL

23

01010-80616

BOLT

24

01643-30623

WASHER

25

20Y-54-K7421

PLATE

26

01010-81230

BOLT

27

01643-31232

WASHER

28

20E-54-K2230

BAR

29

207-54-K2490

SEAL

30

20Y-54-29261

SEAL

31

20Y-54-11611

STOPPER

32

01580-11008

NUT

33

01010-81235

BOLT

|33

01010-51235

BOLT

34

01643-31232

WASHER

|34

01643-31232

WASHER

35

20Y-54-33290

PLATE

36

208-54-K2421

COVER

37

01010-81230

BOLT

38

01643-31232

WASHER

39

01010-81230

BOLT

40

01643-31232

WASHER

41

20Y-54-K7741

SHEET

42

20Y-54-K9281

BRACKET

43

01010-81240

BOLT

44

01643-31232

WASHER

45

208-54-K2620

SHEET

46

208-54-K2630

SHEET

47

208-54-K2640

SHEET

48

208-54-K3730

COVER

49

01010-81230

BOLT

50

01643-31232

WASHER
