Запчасти Komatsu PC450LC-6K ОБОГРЕВАТЕЛЬ. И ТРУБЫ(№K-K999) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-977-K391

HEATER ASS'Y

2

20Y-977-K380

DUCT

3

20Y-977-K310

CABLE

4

20Y-977-K321

CABLE

|4

20Y-977-K320

CABLE

5

01010-81230

BOLT

6

01643-31232

WASHER

7

20Y-977-K340

CONTROLLER ASS'Y

8

01023-10510

SCREW

9

20Y-977-K230

SEAL

10

208-54-K3250

COVER

|10

208-54-68410

COVER

11

208-54-62420

SHEET

12

208-54-K3260

SHEET

|12

208-54-62430

SHEET

13

208-54-K3270

SHEET

|13

208-54-62610

SHEET

14

208-54-K3280

SHEET

|14

208-54-62620

SHEET

15

01010-81230

BOLT

16

01643-31232

WASHER

17

09483-00554

HOSE

18

09483-00550

HOSE

19

208-977-6820

HOSE

20

09480-10100

CLAMP

21

421-07-11550

CLIP

22

20Y-03-11220

COLLAR

23

01010-81260

BOLT

24

01643-31232

WASHER

25

01010-81225

BOLT

26

01010-81230

BOLT

27

01643-31232

WASHER

28

207-979-6180

BRACKET

29

01010-81225

BOLT

30

01643-31232

WASHER

31

04434-52512

CLIP

32

22S-62-26210

SPACER

33

01011-81205

BOLT

34

01643-31232

WASHER

35

04434-52512

CLIP

36

20Y-03-11220

COLLAR

37

01010-81260

BOLT

38

01643-31232

WASHER

39

421-07-11550

CLIP

40

20Y-03-11220

COLLAR

41

01010-81260

BOLT

42

01643-31232

WASHER

43

04434-52512

CLIP

44

08034-00536

BAND

45

04434-52512

CLIP

46

207-977-5120

BRACKET

47

01010-81225

BOLT

48

01643-31232

WASHER

49

08034-00519

BAND

50

07281-00259

CLAMP

51

09484-00560

CONNECTOR

52

208-977-K160

ELBOW

53

208-03-68310

NET

54

01010-81035

BOLT

55

20Y-43-15410

WASHER

56

208-54-K3290

SHEET
