Запчасти Komatsu PC450LC-6K ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ)(№K-K999) СИСТЕМА ОХЛАЖДЕНИЯ

1

208-03-68350

RADIATOR CORE ASS'Y

|1

208-03-68240

RADIATOR CORE A.

2

208-03-58370

CAP

3

205-03-62660

PLUG

4

07000-01007

O-RING

5

205-03-71230

HOSE

6

20Y-03-11330

CLIP

7

01010-81225

BOLT

8

01643-31232

WASHER

9

208-03-68340

OIL COOLER ASS'Y

|9

208-03-61120

OIL COOLER ASS'Y

10

01010-81225

BOLT

11

01643-31232

WASHER

12

01010-81225

BOLT

13

01643-31232

WASHER

14

208-03-K2140

SEAL

|14

207-03-51171

SEAL

15

208-03-K2160

SEAL

|15

207-03-51181

SEAL

16

208-03-61250

SHEET

17

208-03-61240

SHEET

18

208-03-61260

SHEET

19

208-03-K2270

FRAME

|19

208-03-61130

FRAME

20

208-03-K2280

FRAME

|20

208-03-61140

FRAME

21

208-03-61171

NET

22

01434-10620

BOLT¤ WING

23

01643-30623

WASHER

24

208-03-K2110

SHROUD,FAN

|24

208-03-68130

SHROUD,FAN

25

208-03-68151

NET

26

01010-81225

BOLT

27

01643-31232

WASHER

28

208-03-68320

NET

29

01010-81025

BOLT

30

01643-31032

WASHER

31

208-03-K2290

TUBE

|31

208-03-61211

TUBE

32

07283-24949

CLIP

33

01599-01011

NUT

34

01643-31032

WASHER

35

208-03-61221

BRACKET

36

07000-03045

O-RING

37

01010-81240

BOLT

38

01643-51232

WASHER

39

01010-81025

BOLT

40

01643-31032

WASHER

41

208-03-K2310

SHEET

42

208-03-K2120

SHEET

43

208-03-K2130

SHEET

44

208-03-K2250

SHEET

45

208-03-K2260

SHEET

46

208-03-K2170

SHEET

47

208-03-K2210

COVER

48

01010-81220

BOLT

49

01643-31232

WASHER

50

208-03-K2180

SHEET

51

208-03-K2230

COVER

52

01010-81220

BOLT

53

01643-31232

WASHER

54

208-03-K2150

SHEET

55

208-03-K2240

SHEET
