Запчасти Komatsu PC450LC-6K-KE ЦИЛИНДР КОВША ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

208-63-X2531

BUCKET CYLINDER G.

|1

208-63-02531

BUCKET CYLINDER A.

1

208-63-73341

CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

208-63-73320

ROD

6

707-76-10140

BUSHING

7

208-70-12231

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-16920

HEAD

10

198-63-94170

SEAL,DUST (KIT)

11

07179-13126

RING,SNAP

12

707-52-90850

BUSHING

13

707-51-11030

PACKING,ROD (KIT)

14

707-51-11630

RING,BUFFER (KIT)

15

707-35-91640

RING,BACK-UP (KIT)

16

07000-15150

O-RING (KIT)

17

01010-82085

BOLT

18

707-88-75310

WASHER

19

707-36-16380

PISTON

20

01310-01216

SCREW

21

707-44-16180

RING,PISTON (KIT)

22

707-39-16820

RING,WEAR (KIT)

23

707-44-16910

RING

24

07001-05100

RING,BACK-UP (KIT)

25

07000-15100

O-RING (KIT)

26

208-63-73371

TUBE

27

208-63-73180

TUBE

28

01435-01055

BOLT

29

07000-13035

O-RING (KIT)

30

707-88-87130

BRACKET

31

707-88-87140

BAND

32

01010-81240

BOLT

33

01643-51232

WASHER

34

707-88-10150

CLAMP

35

01010-81245

BOLT

36

01643-31232

WASHER

37

07000-13032

O-RING

38

07378-11000

HEAD

39

07371-31049

FLANGE,SPLIT

40

07372-21035

BOLT

41

01643-51032

WASHER
