Запчасти Komatsu PC450LC-6 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC450LC-6 - МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
5
6
7
7
8
8
9
10
11
12
13
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
39
39
40
41
42
43

Артикул

Название

Примечание

Количество

|$4

706-88-00151

MOTOR ASS'Y

|$5

706-88-00150

MOTOR ASS'Y

|$6

706-88-00111

MOTOR ASS'Y

|$7

706-88-00110

MOTOR ASS'Y

1

706-88-40140

CASE,MOTOR

1

706-88-40110

CASE,MOTOR

|$15

706-88-00020

END COVER SUB ASS'Y

2

COVER,END

3

706-88-00010

PLATE ASS'Y,VALVE

4

SPOOL

5

PLUG

6

708-8K-15190

PIN,DOWEL

7

706-77-72280

PLUG

8

07002-12034

O-RING

9

20B-27-11210

BLEEDER

10

706-88-50030

PISTON

11

706-88-50010

PIN

12

706-87-51120

SCREW

13

706-75-74540

VALVE

14

706-75-74550

SPRING

15

706-75-74850

PLUG

16

07002-13334

O-RING

17

706-78-71170

PISTON

17

706-78-71160

PISTON

18

708-8H-36121

SPRING

19

706-78-71140

PLUG

20

07002-13634

O-RING

21

706-88-50110

SLEEVE

22

07002-15234

O-RING

23

07000-13035

O-RING

24

07001-03035

RING,BACK-UP

25

07000-13038

O-RING

26

07001-03038

RING,BACK-UP

27

706-8E-14170

SPRING

28

706-88-50140

SPOOL

29

706-88-50160

PLUG

30

07002-13034

O-RING

31

706-88-50170

PLUG

32

07002-13034

O-RING

33

04260-00793

BALL

34

706-8E-14110

PLUG

35

07002-11023

O-RING

36

708-8E-16180

VALVE

37

706-78-71150

VALVE

38

708-8E-16160

PLUG

39

07002-11023

O-RING

40

706-78-71130

PLUG

41

07002-11423

O-RING

42

07000-11007

O-RING

43

07001-01007

RING,BACK-UP

Выбрано товаров: 50
