Запчасти Komatsu PC450-8 БЫСТРОСЪЕМН. МЕХ-М ЛИНИИ (PPC ТРУБЫ) ( АКТУАТОР) (№K-K) H ГИДРАВЛИКА

1

02760-002A3

HOSE

2

02760-00203

HOSE

3

02760-002A7

HOSE 750MM

4

02760-00208

HOSE 800MM

5

08034-20519

BAND

6

20Y-62-22840

BAND BLACK, BLACK

7

20Y-62-22860

BAND BROWN, BROWN

8

02760-00213

HOSE

9

207-62-72640

HOSE 1400MM

10

20Y-62-22790

BAND RED, RED

11

02760-00205

HOSE

12

04435-51512

CLIP

13

195-01-16261

COLLAR

14

01011-81235

BOLT

15

01643-31232

WASHER

16

04434-52512

CLIP

17

08034-20519

BAND

18

208-62-72570

HOSE 1200MM

19

208-62-72580

HOSE 1700MM

20

20Y-62-22810

BAND YELLOW

21

08034-20519

BAND

22

208-62-72570

HOSE 1200MM

23

208-62-72580

HOSE 1700MM

24

20Y-62-22840

BAND BLACK, BLACK

25

20Y-62-22860

BAND BROWN, BROWN

26

08034-20519

BAND

27

08034-20310

BAND

28

11Y-62-12160

ELBOW

29

07002-11423

O-RING

30

02896-11008

O-RING

31

20Y-62-43430

BLOCK

32

20Y-62-43450

PLATE

33

01010-80830

BOLT

34

01643-30823

WASHER

35

20Y-62-16630

NIPPLE

36

201-60-11390

O-RING

37

20Y-62-19560

O-RING

38

07002-11423

O-RING

39

206-06-61130

SWITCH

40

08034-20536

BAND
