Запчасти Komatsu PC450-8 СОЛЕНОИДНЫЙ КЛАПАН (КОРПУС) H [ГИДРАВЛИКА]

1

208-62-71791

BRACKET

2

01010-81090

BOLT

3

01643-31032

WASHER

4

08034-20519

BAND

5

02760-00325

HOSE

6

02760-00324

HOSE, FACE SEAL TYPE

7

20Y-62-22790

BAND, RED

8

20Y-62-22810

BAND, YELLOW

9

08034-20536

BAND

10

02760-00207

HOSE, FACE SEAL TYPE

11

11Y-62-29480

HOSE

12

02761-00214

HOSE, FACE SEAL TYPE

13

20Y-62-22810

BAND, YELLOW

14

20Y-62-22820

BAND, BLUE

15

20Y-62-22860

BAND, BROWN

16

08034-20519

BAND

17

02764-002A8

HOSE, FACE SEAL TYPE

18

02764-00209

HOSE, FACE SEAL TYPE

19

20Y-62-22820

BAND, BLUE

20

02760-00304

HOSE, FACE SEAL TYPE

21

04434-51912

CLIP

22

01010-81225

BOLT

23

01643-31232

WASHER

24

08034-20536

BAND

25

04435-51512

CLIP

26

176-38-41350

SPACER

27

01010-81285

BOLT

28

01643-31232

WASHER

29

04435-51512

CLIP

30

01010-81225

BOLT

31

01643-31232

WASHER

32

04434-51412

CLIP

33

142-03-11160

SPACER

34

01010-81260

BOLT

35

01643-31232

WASHER

36

04434-51012

CLIP

37

01010-81220

BOLT

38

01643-31232

WASHER

39

04435-51312

CLIP

40

01643-31232

WASHER
