Запчасти Komatsu PC450-8 СОЛЕНОИДНЫЙ КЛАПАН (ВНУТР. ЧАСТИ, СОЛЕНОИДНЫЙ КЛАПАН) H [ГИДРАВЛИКА]

|$1

207-60-71311

VALVE ASSEMBLY

1

BLOCK

2

20Y-60-32121

SOLENOID ASSEMBLY

3

07000-12016

O-RING

4

07000-12011

O-RING

5

NY07207-11700

TUBE

6

NY07529-10200

TUBE

7

NY07529-10300

TUBE

8

NY07529-10400

TUBE

9

NY07529-10500

TUBE

10

NY07529-10600

TUBE

11

NY07207-11800

TUBE

12

NY89103-00199

BAND, BLACK

13

NY89103-00089

BAND, BLUE

14

NY89103-00091

BAND, RED

15

NY89103-00183

BAND, YELLOW

16

NY89103-00092

BAND, GREEN

17

NY89103-00144

BAND, BROWN

18

NY89103-00139

BAND, PINK

19

NY05062-1170A

PLUNGER

20

NY05062-11800

SPRING

21

07000-11010

O-RING

22

NY06277-1320A

PLUG

23

NY80000-02200

PLUG

24

NY16207-10200

SLEEVE

25

NY06339-10200

SPRING

26

NY07493-10200

SPOOL

27

NY16207-10300

SPOOL

28

NY81446-05012

BOLT

29

NY09000-11400

PLATE

30

NY80000-02100

PLUG

31

07000-11008

O-RING

32

NY84110-00248

SCREW

33

NY07926-10100

PLATE

34

NY01720-10600

STOPPER

35

07002-11423

O-RING

36

07040-11409

PLUG
