Запчасти Komatsu PC450-8 РУКОЯТЬ (MM, УСИЛ. ТИП) (ВНУТР. ЧАСТИ) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

|$1

707-01-XMK52

CYLINDER ASSEMBLY,(FINAL COOTING)

|$2

707-01-XCW52

CYLINDER GROUP

1

707-13-16871

CYLINDER

2

707-58-11811

ROD, PISTON

3

707-76-10130

BUSHING

4

07145-00100

SEAL, DUST\((K04)\)

5

07020-00000

FITTING, GREASE

6

707-76-10140

BUSHING

7

208-70-73530

SEAL, DUST\((K04)\)

8

07020-00000

FITTING, GREASE

9

707-27-16580

HEAD, CYLINDER

10

707-56-11740

SEAL, DUST\((K04)\)

11

07179-13126

RING, SNAP

12

707-52-90851

BUSHING

13

707-51-11030

PACKING, ROD\((K04)\)

14

707-51-11650

RING, BUFFER\((K04)\)

15

707-35-91640

RING, BACK-UP\((K04)\)

16

07000-15150

O-RING\((K04)\)

17

01010-82085

BOLT

18

707-88-75310

WASHER

19

707-75-11040

RING, SNAP

20

707-36-16580

PISTON

21

707-44-16150

RING, PISTON\((K04)\)

22

707-39-16120

RING, WEAR\((K04)\)

23

707-44-16910

RING

24

07000-B5100

O-RING\((K04)\)

25

07001-05100

RING, BACK-UP\((K04)\)

26

01310-01216

SCREW

27

707-86-12580

TUBE

28

707-86-12570

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING\((K04)\)

32

707-88-25390

BRACKET

33

707-88-26690

BAND

34

07372-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

CLAMP

37

01010-81245

BOLT

38

01643-31232

WASHER
