Запчасти Komatsu PC450-8 ЦИЛИНДР СТРЕЛЫ(ПРАВ.) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

|$1

707-01-XMK31

CYLINDER ASSEMBLY,(FINAL COOTINGЈ©

|$2

707-01-XCW31

CYLINDER GROUP

1

707-13-16861

CYLINDER

2

707-58-11490

ROD, PISTON

3

707-76-10290

BUSHING

4

07145-00100

SEAL, DUST\((K02)\)

5

07020-00000

FITTING, GREASE

6

07043-00108

PLUG, TAPER

7

707-76-11220

BUSHING

8

07145-00110

SEAL, DUST\((K02)\)

9

707-71-31670

COLLAR

10

707-35-91640

RING, BACK-UP\((K02)\)

11

07000-15150

O-RING\((K02)\)

12

707-71-61140

PLUNGER

13

707-27-16580

HEAD, CYLINDER

14

707-56-11740

SEAL, DUST\((K02)\)

15

07179-13126

RING, SNAP

16

707-52-90851

BUSHING

17

707-51-11030

PACKING, ROD\((K02)\)

18

707-51-11650

RING, BUFFER\((K02)\)

19

707-35-91640

RING, BACK-UP\((K02)\)

20

07000-15150

O-RING\((K02)\)

21

01010-82085

BOLT

22

707-88-75310

WASHER

23

707-75-11040

RING, SNAP

24

707-36-16580

PISTON

25

707-44-16150

RING, PISTON\((K02)\)

26

707-39-16120

RING, WEAR\((K02)\)

27

707-44-16910

RING

28

07000-B5100

O-RING\((K02)\)

29

07001-05100

RING, BACK-UP\((K02)\)

30

01310-01216

SCREW

31

707-86-12560

TUBE

32

707-86-00940

TUBE

33

707-87-14700

PLUG

34

07002-63034

O-RING\((K02)\)

35

07372-21060

BOLT

36

01643-51032

WASHER

37

07000-13035

O-RING\((K02)\)

38

707-88-25380

BRACKET
