Запчасти Komatsu PC450-8 ЦИЛИНДР КОВША(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU941

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0F821

CYLINDER ASS'Y

1

707-13-16870

CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-11810

ROD

6

707-76-10140

BUSHING

7

208-70-73530

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-16580

HEAD

10

198-63-94170

SEAL,DUST (KIT)

11

07179-13126

RING,SNAP

12

707-52-90850

BUSHING

13

707-75-11040

RING,SNAP

14

707-51-11030

PACKING,ROD (KIT)

15

707-51-11640

RING,BUFFER (KIT)

16

707-35-91640

RING,BACK-UP (KIT)

17

07000-15150

O-RING (KIT)

18

01010-82085

BOLT

19

707-88-75310

WASHER

20

707-36-16580

PISTON

21

01310-01216

SCREW

22

707-44-16180

RING,PISTON (KIT)

23

707-39-16120

RING,WEAR (KIT)

24

707-44-16910

RING

25

07001-05100

RING,BACK-UP (KIT)

26

07000-15100

O-RING (KIT)

27

707-86-12580

TUBE

28

707-86-12570

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING (KIT)

32

707-88-25390

BRACKET

33

01010-81245

BOLT

34

01643-31232

WASHER

35

707-88-10150

CLAMP

36

07372-21240

BOLT

37

01643-51232

WASHER

38

707-88-33040

CAP

39

07371-31049

FLANGE,SPLIT

40

07372-21035

BOLT

41

01643-51032

WASHER

|$46

707-99-72240

SERVICE KIT
