Запчасти Komatsu PC450-7K ГИДР. БАК. ГИДРАВЛИКА

1

208-60-K1170

TANK

2

20Y-60-K1480

GAUGE

3

07044-12412

PLUG

4

07002-12434

O-RING

5

207-62-72171

ELBOW

6

07002-12434

O-RING

7

02896-11018

O-RING

8

02782-10522

ELBOW

9

07002-12434

O-RING

10

02896-11005

O-RING

11

02782-10315

ELBOW

12

07002-12034

O-RING

13

02896-11009

O-RING

14

207-62-72110

UNION

15

07002-13334

O-RING

16

207-62-64740

O-RING

17

02782-10315

ELBOW

18

07002-12034

O-RING

19

02896-11009

O-RING

20

02783-10210

ELBOW

21

07002-11423

O-RING

22

02896-11008

O-RING

23

208-60-71120

ELEMENT

24

07069-25400

STRAINER

25

208-60-71160

VALVE ASS'Y

26

07069-34075

SPRING

27

208-60-71130

PLATE

28

07000-15210

O-RING

29

01010-81225

BOLT

30

01643-31232

WASHER

|31

208-60-71140

STRAINER ASS'Y

31

208-60-71150

ROD ASS'Y

32

12R-60-11230

SPRING

33

20Y-60-21320

HOLDER

34

22B-60-11160

STRAINER

35

208-60-61190

COVER

36

07000-15180

O-RING

37

01010-81225

BOLT

38

01643-31232

WASHER

39

198-60-55510

BREATHER,(SEE FIG. Y1890-01A0)

40

17A-60-11310

CAP ASS'Y

41

20Y-60-21470

ELEMENT

42

20Y-60-21460

NECK

43

20Y-60-21340

GASKET

44

01252-70516

BOLT

45

01601-20513

WASHER

46

07285-00155

CLIP

47

07270-61420

TUBE

48

07056-10045

STRAINER

49

04065-04718

RING

50

208-60-71210

SHEET

51

01010-81635

BOLT

52

01643-31645

WASHER

53

195-03-11570

SHIM¤ 1.0MM
