Запчасти Komatsu PC450-7E0 МЕХАНИЗМ ПОВОРОТА ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7K-01040

MOTOR ASS'Y

2

207-26-71240

RING

3

07040-11209

PLUG

4

07002-11223

O-RING

5

208-26-71190

CASE

6

07049-02430

PLUG

7

06000-23124

BEARING

8

06000-22326

BEARING

9

208-26-52242

SHAFT

10

208-26-61290

SEAL

11

208-26-71360

COVER

12

01010-81030

BOLT

13

01643-31032

WASHER

14

07000-15390

O-RING

15

208-26-71181

CARRIER

16

208-26-71140

GEAR

17

207-27-61230

BEARING

18

20Y-27-21250

WASHER

19

207-27-61250

PIN

20

20Y-27-21290

PIN

21

208-26-71230

PLATE

22

205-32-51211

BOLT

23

208-26-71150

GEAR

24

01010-81645

BOLT

25

01643-31645

WASHER

26

208-26-71130

GEAR

27

208-26-71241

PLATE

28

208-26-71170

CARRIER

29

207-26-71520

GEAR

30

22U-26-21320

BEARING

31

22U-26-21240

WASHER

32

207-26-71210

PIN

33

04064-04018

RING

34

208-26-71210

HOLDER

35

04260-01270

BALL

36

207-26-71510

GEAR

37

207-26-71261

PLATE

38

144-60-11151

VALVE

39

07270-21590

TUBE

40

07281-00197

CLAMP

41

01010-81240

BOLT

42

01643-31232

WASHER

43

207-26-71410

GAUGE

44

20Y-26-21350

FILLER

45

07000-15335

O-RING

46

01010-82480

BOLT

47

01643-32460

WASHER
