Запчасти Komatsu PC450-7 CONTOROL КЛАПАН (-АКТУАТОР) (7/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$4

723-49-27503

CONTROL VALVE

|$5

723-49-27502

CONTROL VALVE

|$6

723-49-27501

CONTROL VALVE

|$7

723-49-27500

CONTROL VALVE

|$9

BODY SUB ASS'Y

|$10

BODY SUB ASS'Y

1

BLOCK,VALVE

2

SPOOL

3

723-46-15390

PLUG

4

723-46-15370

RETAINER

5

723-46-15380

RETAINER

6

723-46-14190

SPRING

7

723-46-17840

CASE

8

07430-71380

O-RING

9

01252-60820

BOLT

10

723-46-25610

SPOOL

11

723-46-15330

BOLT

12

723-46-15340

PISTON

13

SEAL

14

700-20-71260

SEAL

15

723-46-14180

SPRING

16

723-46-17850

CASE

17

723-46-17860

CASE

18

723-11-19960

O-RING

19

706-73-71450

PLUG

20

07002-11423

O-RING

21

07430-71380

O-RING

22

01252-60845

BOLT

23

PLUG

24

723-46-17530

O-RING

25

723-11-19130

O-RING

26

723-46-17520

RING,BACK-UP

27

07000-13032

O-RING

28

723-46-17510

O-RING

29

07000-12016

O-RING

30

702-16-53920

O-RING
