Запчасти Komatsu PC450-7-M1 ЦИЛИНДР КОВША ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU790

CYLINDER GROUP,(FINAL COATING)

G-1

707-01-XF700

BUCKET CYLINDER G.

|1

707-01-0F700

CYLINDER ASS'Y

1

707-13-16870

CYLINDER

2

707-76-10330

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-10930

ROD

6

208-70-73510

BUSHING

7

208-70-73530

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-16950

HEAD

10

176-63-56170

SEAL,DUST (KIT)

11

07179-13114

RING,SNAP

12

707-52-90780

BUSHING

13

707-75-10160

RING,SNAP

14

707-51-10030

PACKING,ROD (KIT)

15

707-51-10640

RING,BUFFER (KIT)

16

707-35-91640

RING,BACK-UP (KIT)

17

07000-15150

O-RING (KIT)

18

01010-82085

BOLT

19

707-88-75310

WASHER

20

707-36-16580

PISTON

21

01310-01216

SCREW

22

707-44-16180

RING,PISTON (KIT)

23

707-39-16820

RING,WEAR (KIT)

24

707-44-16910

RING

25

07001-05100

RING,BACK-UP (KIT)

26

07000-15100

O-RING (KIT)

27

707-86-12580

TUBE

28

707-86-12570

TUBE

29

01435-01055

BOLT

30

07000-13035

O-RING (KIT)

31

707-88-25390

BRACKET

32

01435-01235

BOLT

33

707-88-10150

CLAMP

34

01435-01245

BOLT

35

707-88-33040

CAP

36

07371-31049

FLANGE,SPLIT

37

07372-21035

BOLT

38

01643-51032

WASHER

|K

707-99-66240

SERVICE KIT
