Артикул
Название
Примечание
Количество
|1
706-77-01180
MOTOR ASS'Y
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.N1220-51A0 AND N1220-52A0.
1
706-77-43210
CASE,MOTOR
2
706-77-43180
BOLT
3
706-7E-11440
O-RING
4
706-77-40010
BEARING
5
706-77-43840
PLATE,VALVE
6
708-18-13230
PIN
7
706-77-43080
SHAFT,CENTER
8
706-77-43191
BLOCK
9
706-77-42110
SPRING
10
706-77-42130
RING,CENTER
11
706-77-42160
PISTON SUB ASS'Y
12
706-77-42041
SEAT
13
706-77-42051
SPRING
14
706-77-43260
RETAINER
15
706-75-41271
SCREW
16
706-77-43860
SHAFT
17
706-77-43880
BEARING
18
706-77-42890
BEARING
|19
706-77-05010
SPACER KIT
19
SPACER¤ 2.3MM
20
SPACER¤ 2.5MM
21
SPACER¤ 2.7MM
22
04064-06525
RING,SNAP
23
706-77-43060
COVER
24
07000-02125
O-RING
25
706-77-43950
SEAL,OIL
26
04071-00130
RING,SNAP
27
706-77-91540
PLATE
28
706-77-91550
DISC
29
706-77-91580
PISTON,BRAKE
30
07000-15180
O-RING
31
708-8H-15220
O-RING
32
706-75-42830
PIN,DOWEL
33
706-77-91510
SPRING
Выбрано товаров: 36
