Запчасти Komatsu PC450-6K ОХЛАЖД-Е (ТРУБЫ)(№K-K999) СИСТЕМА ОХЛАЖДЕНИЯ

1

208-03-68111

HOSE

2

208-09-11120

CLAMP

3

207-03-51530

CLIP

4

01010-81225

BOLT

5

01643-31232

WASHER

6

207-03-51530

CLIP

7

198-43-15310

COLLAR¤ 10MM

8

01010-81225

BOLT

9

01643-31232

WASHER

10

208-03-68121

HOSE

11

208-09-11120

CLAMP

12

208-03-K1111

CLIP

13

01010-81225

BOLT

14

01643-31232

WASHER

15

20Y-06-15240

TANK ASS'Y

16

205-03-71532

CAP

|15

205-03-71540

PACKING

17

207-03-61230

BRACKET

18

20Y-03-11361

BAND

19

01580-10806

NUT

20

01643-30823

WASHER

21

01010-81230

BOLT

22

01643-31232

WASHER

23

208-03-K1020

HOSE

|23

208-03-K1010

HOSE

24

20E-03-K1190

CLIP

25

208-03-61230

HOSE¤ 1950MM

26

208-03-68181

TANK

27

203-60-31160

TUBE

28

203-60-31100

ELBOW ASS'Y

29

205-03-71280

CAP ASS'Y

30

208-03-K8220

BRACKET

31

01010-81225

BOLT

32

01643-31232

WASHER

33

20E-03-K1190

CLIP

34

07281-00419

CLAMP

35

208-03-68190

ELBOW

36

20X-03-21290

HOSE

37

20E-03-K1190

CLIP

38

208-03-K1160

HOSE

39

07260-22680

HOSE

40

208-03-68211

BRACKET

41

01010-81225

BOLT

42

01643-31232

WASHER
