Запчасти Komatsu PC450-6K-KE ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

208-63-X2521

ARM CYLINDER GROUP

|1

208-63-02521

ARM CYLINDER ASS'Y

1

208-63-63741

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

208-63-63720

ROD

5

707-76-11130

BUSHING

6

07145-00110

SEAL,DUST (KIT)

7

707-71-32900

COLLAR

8

707-35-91840

RING,BACK-UP (KIT)

9

07000-15175

O-RING (KIT)

10

707-71-61320

PLUNGER

11

707-71-60300

PLUNGER

12

04260-00952

BALL

13

707-71-91230

CAP

14

707-27-18960

HEAD

15

195-63-93170

SEAL,DUST (KIT)

16

07179-13136

RING,SNAP

17

707-52-90980

BUSHING

18

707-51-12030

PACKING,ROD (KIT)

19

707-51-12630

RING,BUFFER (KIT)

20

707-35-91840

RING,BACK-UP (KIT)

21

07000-15175

O-RING (KIT)

22

01011-82400

BOLT

23

707-88-75410

WASHER

24

707-36-18520

PISTON

25

01310-01225

SCREW

26

707-44-18280

RING,PISTON (KIT)

27

707-39-18830

RING,WEAR (KIT)

28

707-44-18920

RING

29

07001-05110

RING,BACK-UP (KIT)

30

07000-15110

O-RING (KIT)

31

208-63-63771

TUBE

32

207-63-63180

TUBE

33

01435-01055

BOLT

34

07000-13035

O-RING (KIT)

35

707-88-95810

BRACKET

36

707-88-95800

BAND

37

707-88-95831

BRACKET

38

707-88-95820

BAND

39

01010-51240

BOLT

40

01643-51232

WASHER

41

07283-23442

CLIP

42

01643-31032

WASHER

43

01599-01011

NUT

44

07000-13032

O-RING

45

07378-11000

HEAD

46

07371-31049

FLANGE,SPLIT

47

07372-21035

BOLT

48

01643-51032

WASHER
