Запчасти Komatsu PC450-6 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC450-6 - МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28

Артикул

Название

Примечание

Количество

|1

706-88-00151

MOTOR ASS'Y

|1

706-88-00150

MOTOR ASS'Y

|1

706-88-00111

MOTOR ASS'Y

|1

706-88-00110

MOTOR ASS'Y

1

706-88-40370

O-RING

2

07000-12012

O-RING

3

706-88-40310

BOLT

4

706-88-40660

SHAFT,DRIVE

5

706-88-40880

BEARING

6

706-88-40890

BEARING

7

706-88-40810

RETAINER

8

706-88-05010

SPACER KIT

|8

SPACER¤ 1.6MM

|8

SPACER¤ 1.7MM

|8

SPACER¤ 1.8MM

9

04064-07525

RING,SNAP

10

708-8K-12141

SEAL,OIL

11

706-88-40710

HOUSING

12

07000-02135

O-RING

13

04071-00140

RING,SNAP

14

706-88-40090

BLOCK,CYLINDER

15

706-88-40080

SHAFT,CENTER

16

706-88-40130

RING,CENTER

17

706-88-40060

SPRING

|18

706-88-05020

RETAINER KIT

18

RETAINER

19

SCREW

20

706-88-40162

PISTON SUB ASS'Y

|20

706-88-40160

PISTON SUB ASS'Y

|20

706-88-40161

PISTON SUB ASS'Y

21

706-88-90140

PLATE

22

706-88-90150

DISC

23

706-88-90180

PISTON,BRAKE

24

07000-15240

O-RING

25

706-88-90130

RING,BACK-UP

26

07000-15270

O-RING

27

07001-05270

RING,BACK-UP

28

706-88-90410

SPRING

Выбрано товаров: 38
