Запчасти Komatsu PC45-1 КОЖУХ ШЕСТЕРЕН. ПЕРЕДАЧИ ДВИГАТЕЛЬ

1

YMR001070

FLANGE, GEAR HOUSING

2

YMR000066

STUD

3

YMR001071

HOUSING ASSY., GEAR

5

YMR000295

SEAL, OIL

6

YMR000078

OIL PLUG

7

YMR000083

COVER

8

YMR000457

GASKET

9

YMR000296

PIPE L=18

10

YMR000167

RETAINER

11

YMR000073

O-RING

12

YMR000383

O-RING

13

YMR000384

O-RING

14

YMR000400

BOLT PLATED

15

YMR000402

BOLT PLATED

16

YMR000402

BOLT PLATED

17

YMR000407

SCREW

18

YMR000409

SCREW

19

YMR000412

SCREW

20

YMR000425

NUT

21

YMR000353

NUT

22

YMR000943

WASHER

23

YMR000943

WASHER

24

YMR000053

COVER

25

YMR000388

O-RING

26

YMR000395

SCREW

27

YMR001077

STUD

28

YMR001082

SCREW

29

YMR000083

COVER

30

YMR000457

GASKET

31

YMR000943

WASHER

32

YMR000402

BOLT PLATED

33

YMR001078

GASKET

34

YMR001079

KIT, DRIVING SET

35

YMR001080

BRACKET

37

YMR001085

BEARING

38

YMR000457

GASKET

39

YMR001067

PUMP, HYDRAULIC OIL

40

YMR001087

SCREW

41

YMR001088

STUD
