Запчасти Komatsu PC45-1 ВСАСЫВАЮЩ. ПАТРУБОК - ВОЗДУХООЧИСТИТЕЛЬ ДВИГАТЕЛЬ

1

YMR000546

MANIFOLD, INTAKE

2

YMR000551

GASKET

3

YMR000406

SCREW

4

YMR000134

HEATER, AIR

5

YMR000532

GASKET

6

YMR000406

SCREW

7

YMR000047

PIPE, SUCTION

8

YMR000145

AIR FILTER, ASSY.

9

YMR000525

PAN ASSY., DUST

10

YMR000057

RETAINER

11

YMR000058

BOLT, WING

12

YMR000462

WASHER

13

YMR001091

CASE, ASSY.

14

YMR000516

PLUG

15

YMR000463

SCREEN

16

YMR000523

AIR CLEANER SUPPORT, ASSY.

18

YMR000023

FELT, SUPPORT

19

YMR000141

BRACKET

21

YMR000142

SHEET, RUBBER

22

YMR000524

SUPPORT

24

YMR000143

SHIM

25

YMR000144

DAMPER

26

YMR000372

CLAMP

27

YMR000396

SCREW

28

YMR000401

BOLT PLATED

29

YMR000404

SCREW

30

YMR000514

MANIFOLD, EXHAUST

31

YMR000552

GASKET

32

YMR000353

NUT

33

YMR000411

SCREW

34

YMR000573

STUD

35

YMR000422

STUD

36

YMR000535

GASKET

37

YMR000702

CLAMP

38

YMR001090

CLAMP

39

YMR000703

WASHER

40

YMR000704

SPRING WASHER

41

YMR000705

SCREW

42

YMR000706

NUT
