Запчасти Komatsu PC45-1 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

\0

871070012

ENGINE, ASSY.

1

YMR000570

PIPE

4

YMR000092

LIFTER

5

YMR000401

BOLT PLATED

6

YMR000576

CYLINDER HEAD

11

YMR000052

GUIDE VALVE

13

YMR000174

GUIDE VALVE

14

YMR000071

PLUG

15

YMR000378

PLUG

16

YMR000421

STUD

17

YMR000435

PLUG

18

YMR000437

PLUG

19

YMR000100

VALVE, INLET

20

YMR000101

VALVE EXHAUST

21

YMR000298

SPRING, VALVE

22

YMR000299

RETAINER, SPRING

23

YMR000004

COTTER

24

YMR000065

SEAL, VALVE EXHAUST

25

YMR000085

SEAL, VALVE STEM

26

YMR000172

CAP VALVE

27

YMR000365

PEG

28

YMR000424

NUT

29

YMR000557

SHAFT

30

YMR000203

SUPPORT

31

YMR000204

SUPPORT

32

YMR000169

SPRING

33

YMR000549

SHAFT

36

YMR000460

ROCKER SHAFT

37

YMR000168

TAPPET

39

YMR000173

NUT

40

YMR000423

STUD

41

YMR000574

NUT

42

YMR000961

PROTECTION, NOZZLE

43

YMR000021

SEAT, NOZZLE

44

YMR000022

RETAINER

45

YMR000404

SCREW

46

YMR000408

SCREW

47

YMR000591

COVER

48

YMR000078

OIL PLUG

49

YMR000164

COVER, BREATHER

50

YMR000165

SPLASH-GUARD

51

YMR000166

PROTECTION

53

YMR000550

GASKET

54

YMR000384

O-RING

55

YMR000389

O-RING

56

YMR000402

BOLT PLATED

57

YMR000080

KNOB

58

YMR000382

O-RING

59

YMR000518

RETAINER

60

YMR000597

COLLAR

61

YMR000400

BOLT PLATED
